SKU: M1D2-12-XX-EJD
BRAND: Rockford
Pump up your marine audio with the John Deere Gator M1 12 DVC 2-Ohm Color Optix Marine Subwoofer by Rockford!
Read More
The Black and white Color Optix™ 12” DVC 2-Ohm subwoofers deliver loud, clear, accurate bass, and light the way for your journey! The subwoofers connect with the Rockford Fosgate Color Optix™ Controller and RF Connect App, allowing you to customize your own color patterns. The Element Ready™ design and IPX6 certification makes them truly purpose-built for marine or motorsport applications where protection from damaging UV rays and water spray is essential.
The M1 series of Element Ready™ subwoofers are designed to pair with the Rockford Fosgate Color Optix™ Controller and RF Connect App through its Deutsch™ and Amphenol™ connectors integrated into the basket. This combined with their IP67 certification make these speakers Element Ready™ and truly purpose built for marine applications. To compliment the plug and play connectivity and streamline installation, M1 subwoofers are equipped with a VersaSwitch™ to make changing impedance between 1 and 4 ohms as easy as flipping a switch.
12" DVC 2-Ohm Black Color Optix Marine Subwoofer Features:
- Optixally clear UV stable RGB Lighting Encapsulation
- Ultra-bright wide-angle RGB LEDs provide rich, reliable illumination
- Vented motor design with water-repelling nano coated mesh screen
- 2" (50mm) High Temp Kapton™ Woofer Voice Coil Former
- Fully insulated silicone tinsel leads
- 100% UV Stable ASA plastic frame & grille design stands up to harsh marine environment
- Zinc Nickel-plated Marine grade brass connection terminals
- Industry’s first molded in-frame connectors for simple connectivity in addition to conventional spade terminals
- Integrated Deutsch™/Amphenol™ connectors make wiring connections simple and error proof
- Linear Synthetic Fiber Blend Spiders
- Santoprene VAST Surround
- VAST vertical attach surround technique increases effective radiating cone area up to 25%
- Co-molded surround and mineral filled polypropylene cone body
- Injection molded mineral filled polypropylene cone body with UV inhibitors
- VERSA impedance switch quickly allows series or parallel configuration without additional wiring
Specs:
- Size - 12"
- Nominal Impedance (Ohms) - 1-Ohm or 4-Ohm Switchable
- Power Handling (Watts RMS) - 300 Watts RMS 1200 Watts PEAK
- Voice Coil Type - Dual Voice Coil
- Voice Coil Diameter - 2" (50 mm)
- Frequency Response - 20 Hz - 750 Hz
- Magnet Weight (oz) - 39.75 oz. (1.13 Kg)
- Fs (Hz) - 26
- Re (Ohms) - 3.8
- Le (mH) - 2.02
- Qms - 7.47
- Sd (cm2) - 585.4
- Qes - 0.57
- Qts - 0.53
- Vas - 114.2
- SPL (dB @ 1w/1m) - 92
- Xmax (mm) - 6.0
- Woofer Displacement - 3.49 cu. ft. (0.12 Liters)
- Speaker Connector - Deutsch™
- Cutout Diameter - 10.85 in. (275.6 mm)
- Mounting Depth - 6.65 in. (169.1 mm)
